Spoorbreedte :

5"

7¼"

Grootste breedte (locs/wagens)

270 mm

370 mm

Afstand buffers (hart tot hart)

160 mm

220 mm

Afstand buffers (hart tot kop van de rail)

90 mm

125 mm

Wielbreedte (inclusief flens) (minimum)

14,5 mm

21 mm

Hoogte van de flens

4 mm

5 mm

Normale straal voor bochten

13 m

21 m

Kleinste straal voor bochten

6

17 m

Maximale snelheid

10 km/u

15 km/u

Keteldruk (normaal)

6 bar

8 bar

Gemiddeld locgewicht (3-asser)

110 kg

270 kg

Abmessungen für Puffer / Kupplung bei Normalspurfahrzeugen

Spoor
   Bufferafstand A
   Bufferhoogte H
O
39,5 +0,7/-0,7
23,6 +0,7/-1,0
I
54,5 +0,5/-0,5
33,0 +0,5/-1,5
3
109,4 +0,6/-0,6
66,3 +0,5/-5,0
5
159,0 +1,0/-1,0
96,5 +0,5/-7,5
7
219,0 +1,5/-1,5
132,5 +1,0/-10,5
10
318,0 +2,0/-2,0
193,0 +1,0/-15,0
